1000BASE-LX Duplex LC 1.25G 1310nm 20km DOM SFP
- Brand: Various
- Specs:-
- Type: Single mode SFP (with DOM support)
- ::Ethernet Channel Speed: 1.25 GB/s
- ::Fibre Channel Speed: 1.06 Gb/s
- ::Form Factor: SFP (BiDi)
- ::Mode: Single Mode
- ::Supported Distance: 20km
- ::Wavelength: 1310nm / 1550nm
- ::Optical Eye Diagram: IEEE 802.3z and ANSI Fibre Channel Compatible
- ::Input Differential Impendence (Min) (Max): 90, 110 Ohm
- ::Data Input Swing Differential (Min) (Max): 500, 2400 mV
- ::Output differential impendence (Typ): 100 Ohm
- ::Data Input Swing Differential (Min) (Max): 370, 2000 mV
- ::Supply Voltage (Min) (Max): 3.15, 3.45 V
- ::Operating Case Temperature (Min) (Max): 0, 70 ℃
- ::Voltage: 3-15 ~ 3.45 V
- ::Bias Current: 10 ~ 80 mA
- ::Tx Power: -9 ~ -3 dBm
- ::Rx Power: -26~-3 dBm
- Compatibility:
- ::Cisco: Often compatible with Cisco's GLC-LH-SMD or similar 1000BASE-LX/LH parts.
- ::Juniper: Compatible with parts like EX-SFP-1GE-LX-20 (for 20km versions).
- ::Arista Networks
- ::Brocade
- ::Dell / Dell Networking
- ::HPE / Aruba
- ::Extreme Networks
- ::Fortinet
- ::Ubiquiti (UniFi)
- ::MikroTik
- ::D-Link
- ::Netgear
- ::Huawei
- Condition: New
- Warranty: 1 (one) year Tekmart Africa warranty
-
INT081125ERMOS2025
**Eligible for immediate collection / shipping upon order confirmation*
The 1000BASE-LX Duplex LC 1.25G 1310nm 20km DOM SFP is a type of Small Form-factor Pluggable (SFP) optical transceiver that is highly compatible with a vast range of networking equipment from numerous vendors, provided the equipment has an MSA-compliant SFP port.
This module is your answer for efficient and cost-effective single-mode fibre deployments.
The bi-directional modules redefine connectivity standards with a powerful design optimised for 1.25 Gbps transmission over distances of up to 20km.
They feature a smart SFP package with LC connectors, ensuring cross-vendor compatibility. What distinguishes them is their novel application of bi-directional technology, which enables duplex transmission on a single fibre by utilising two distinct wavelengths for TX and RX on the same optical strand.
This not only improves performance but also significantly lowers installation costs.
They have a choice between those with a 1310nm FP laser and a 1550nm PIN photodetector or the SM100GSB-20B with a 1550nm DFB laser and a 1310nm PIN photodetector to meet your specific requirements.
