Huawei OceanStor 5300

## **Overview** ## **5300V3-32G-AC-3** Huawei OceanStor 5300 V3 is a Mid-range unified storage system with secure, reliable, efficient features for multiple applications, heterogeneous storage consolidation, disaster recovery, fast data growth. Huawei OceanStor 5300V3-32G-AC-3 integrates Dual controllers with 16GB cache per controllers, 8 Gigabit ports in 2U spaces and supports disk enclosure expansion, which can supports up to 500 disks. Huawei OceanStor 5300 V3 Supports Smart series software including SmartDedupe & SmartCompression, SmartThin, SmartPartition, SmartTier, SmartMotion, and SmartQoS and supports data protection software including HyperSnap, HyperCopy, HyperClone, HyperMirror, HyperReplication. ### **Product DetailsFigure 2 shows the front view of a 2 U 25-disk controller enclosure.** Note: 1 Coffer disk label 2 Disk module handle 3 Disk module latch 4 Information plate (with ESN) 5 ID display of the controller enclosure 6 Power indicator/Power button **Figure 3 shows the rear view of a controller enclosure.** Note: 1 Power-BBU module 2 Power-BBU module handle 3 Power-BBU module latch 4 SmartIO port The SmartIO port is used to connect to the 8 Gbit/s Fibre Channel port, 16 Gbit/s Fibre Channel port, 10 Gbit/s FCoE port (VN2VF) or 10 Gbit/s Eth optical port of the application server. 5 Interface module handle 6 16 Gbit/s Fibre Channel port The 16 Gbit/s Fibre Channel port is used to connect to the 16 Gbit/s Fibre Channel port of the application server. 7 Power socket 8 Serial port The serial port is used to connect to the maintenance terminal. 9 Maintenance network port The maintenance network port is designed for special maintenance in emergency. 10 Management network port The management network port is used to connect to the maintenance terminal. 11 USB port Reserved function 12 Mini SAS HD expansion port The mini SAS HD expansion port is used to connect to the disk enclosure. 13 Controller handle **Figure 4 shows the front view of a
