540-BBVO Dell Intel X710-T4 Quad-Port 10Gb Ethernet Adapter

Dell Intel X710-T4 Quad-Port 10Gb Ethernet Converged Network Adapter LP DPN: 540-BBVO,08XJ7,8XJ7

• Brand: Dell
• Part #: 540-BBVO
• Alt Part #(s): 008XJ7 (or simply 08XJ7)
• Specs:-
• ::Type: Network Adapter / Converged Network Adapter (CNA)
• ::Description: Dell-branded Intel X710-T4 Quad-Port 10GbE Base-T adapter.
• ::Controller: Intel Ethernet Controller X710-T4
• ::Ports: 4 ports
• ::Connectivity: 10 Gigabit Ethernet (10GbE)
• ::Interface: Base-T (RJ45 copper twisted-pair)
• ::Data Transfer Rate: 10 Gbps
• ::Interface (Bus) Type: PCI Express (PCIe) 3.0 x8
• ::Interface Slot: Must have an available PCIe 3.0 x8 slot or higher.
• ::Form Factor: Typically low profile (LP) or comes with an LP bracket.
• Compatibility:-
• ::Dell PowerEdge servers that MUST have an available PCIe 3.0 x8 slot or higher.
• ::15th Generation (15G) PowerEdge Servers-the 540-BBVO is compatible with Dell PowerEdge 15G servers (e.g., R650, R750).
• ::16th Generation (16G) PowerEdge Servers-the 540-BBVO is often compatible with Dell PowerEdge 16G servers (e.g., R660, R760), but it is generally considered an older generation option.
• Condition: New
• Warranty: 1 (one) year Tekmart Africa warranty
•

The SKU:540-BBVO is a Dell part number and refers to a Dell Intel X710-T4 Quad-Port 10Gb Ethernet Converged Network Adapter (CNA).

This type of adapter is commonly used in Dell PowerEdge servers to provide high-speed networking capabilities for demanding workloads, data centers, and virtualization environments.

**The adapter is designed for Dell servers that have an available PCI Express (PCIe) 3.0 x8 slot or higher.**

They are compatible with a wide range of Dell EMC PowerEdge servers, primarily those in the 13th and 14th generation of PowerEdge servers.

The adapter typically ships with a Low Profile (LP) bracket, but it may be used in full-height slots depending on the included brackets or system chassis.

When searching for the 540-BBVO, you may encounter other Dell part numbers that are variations of the Intel X710 Quad-Port adapter, but with different features (like port type or bracket size) as in below:-

540-BBVB-as Full Height (vs. 540-BBVO's Low Profile-this one listed here).

The X710 adapter's PCIe 3.0 x8 interface is compatible with the slots (which are often PCIe 5.0) in 16G servers, though the card will operate at the slower PCIe 3.0 speed.

Lastly and in both cases, you must ensure you have an available PCIe expansion slot of the correct size and that the card's low-profile bracket (which this 540-BBVO adapter typically is) matches the available riser or slot configuration in your specific server model.
